The New Holland L328 Skid Steer is designed for heavy-duty tasks in construction, landscaping, and agriculture. The L328 produces 74-horsepower and 232 foot pounds of peak torque. The L328 boasts a rated operating capacity of 2,800 pounds and a tipping load of 5,600 pounds, making it suitable for heavy lifting and material handling. Its vertical lift Super Boom® design provides a dump height of 100 inches and a reach of 31.9 inches, ideal for loading high-sided trucks. The hydraulic system is capable of delivering standard flow rates of 24.2 gallons per minute, with an optional high-flow system that increases this to 37.6 gallons per minute for demanding attachments.
Here are the key specifications of the New Holland L328 Skid Steer:
Specifications
- Engine Model
- FPT / F5H FL463A*F001
- Engine Type
- Turbocharged diesel
- Fuel Tank
- 25.5 gal (96.5 L)
- Power
- 74 hp
- Torque
- 232 lb-ft (314 Nm)
- Rated Operating Load (50% Tip)
- 2,800 lbs (1,270 kg)
- Tipping Load
- 5,600 lbs (2,540 kg)
- Operating Weight
- 7,895 lbs (3,580 kg)
- Breakout Force (Bucket)
- 8,620 lbs
- Breakout Force (Lift)
- 6,030 lbs
- Travel Speed (Low)
- 7.0 mph (11.3 kph)
- Travel Speed (High)
- 10.5 mph (16.9 kph)
- Lift Path
- Vertical
- Dump Height Reach
- 31.9 inches (81 cm)
- Hydraulic Type
- Gear
- Hydraulic Flow (Standard)
- 24.2 gpm (91.5 lpm)
- Hydraulic Flow (Optional)
- 37.6 gpm (142.5)
- Hydraulic Pressure
- 3,046 psi (210 bar)
- Wheelbase
- 52 in (132 cm)
- Length (with bucket)
- 147 in (373.4 cm)
- Length (with extended bucket)
- 152.2 in (386.6 cm)
- Height (Bucket hinge pin)
- 129.4 in (328.7 cm)
See all New Holland Skid Steers currently for sale
Visit our New Holland landing page to find dealers, stay up to date on the latest news, read reviews and watch the latest farm equipment videos.
For complete details view the product brochure.
