John Deere 335 P Compact Track Loader

Published: June 13, 2024
,

The John Deere 335 P Compact Track Loader is a versatile and compact solution for operating in tight spaces and challenging terrain. Key features include:

  1. Engine: equipped with a 118 horespower turbo diesel engine producing 291 lb ft of torque.
  2. Compact Design: Its compact size allows for excellent maneuverability in tight spaces.
  3. Lift Capacity: The 335 P has an operating capacity of 4,025 lbs (1827 kg), a tipping load of 11,500 lbs (5221 kg) and height to hinge pin of 11 feet allowing it to load tandem-axle dump trucks, fill hoppers, and feed mixers.
  4. Operator Comfort: The loader is designed with operator comfort in mind, featuring an ergonomic cab with adjustable seating, intuitive controls, and good visibility.
  5. Attachments: It supports a wide range of attachments, including buckets, forks, and hydraulic tools, allowing it to perform multiple functions.
  6. Advanced Technology: The machine includes advanced technology features such as automated grading systems and telematics for improved efficiency and job site management.

Here are the key specifications of the John Deere 335 P Compact Track Loader:

Specifications

Engine Model
Yanmar 4TNV94FHT
Power
118 hp
Engine Type
Diesel
Rated Operating Capacity
1827 kg (4,025 lb.)
Operating Weight
5584 kg (12,300 lb.)
Tipping Load
5221 kg (11,500 lb)
Travel Speed
13.7 kph (8.5 mph)
Height to Hinge Pin
3.35 m (11 ft)
Dump Height with Foundry Bucket
2.69 m (8 ft 10 in)
Hydraulic Flow (Standard)
94.6 lpm (25 gpm)
Hydraulic Flow (High Flow)
1666.6 lpm (44 gpm)
Hydraulic Pressure
4,000 psi (27,579 kPa)
Hydraulic Horsepower (Standard)
38.1 kW (51.1 hp)
Hydraulic Horsepower (High Flow/High Pressure)
76.6 kW (102.7 hp)
Track Width
450 mm (17.7 in)
Length without Bucket
3.17 m (10 ft 5 in)
Length with Foundry Bucket
3.84m (12 ft 7 in)
Width without Bucket
2.00 m - 2.22 m (depending on track size)
Height to ROPS
2.22 m (7 ft 3 in)
Ground Clearance
0.25 m (9.8 in)

See all John Deere Track Loaders currently for sale

Visit our John Deere landing page to find dealers, stay up to date on the latest news, read reviews and watch the latest farm equipment videos.

For complete details view the product brochure.
