The John Deere 334 P is a powerful Skid Steer with 118 horsepower, and compact design allows creating capable maneuverability on a farm or job site. Key features include:
- Engine: equipped with a 118 horespower turbo diesel engine producing 291 lb ft of torque.
- Compact Design: Its compact size allows for excellent maneuverability in tight spaces.
- Lift Capacity: The 335 P has an operating capacity of 4,000 lbs (1816 kg), a tipping load of 8,000 lbs (3,632 kg) and height to hinge pin of 11 feet allowing it to load tandem-axle dump trucks, fill hoppers, and feed mixers.
- Operator Comfort: Electrohydraulic (EH) ISO-pattern joystick controls that allow customized machine operations based on operator preference come standard. EH four-way controls, including EH foot control, ISO joystick control, H-pattern joystick control, and ISO and foot controls, are optional.
- Attachments: It supports over 100 available John Deere attachments, including buckets, forks, and hydraulic tools. Hydraulic flow of 44 gallons per minute empowers the addition of high- or super-flow attachments.
- Advanced Technology: Optional Onboard Grade indicate provides a real-time readout of cross-slope (machine roll) and mainfall slope (machine pitch)on the in-cab monitor.
Here are the key specifications of the John Deere 334 P Skid Steer:
Specifications
- Engine Model
- Yanmar 4TNV94FHT
- Power
- 118 hp
- Engine Type
- Diesel
- Rated Operating Capacity
- 1,816 kg (4,000 lb.)
- Operating Weight
- 4,660 kg (10,264 lb.)
- Tipping Load
- 3,632 kg (8,000 lb)
- Travel Speed (Low)
- 12.1 kph (7.5 mph)
- Travel Speed (High)
- 19.3 kph (12 mph)
- Height to Hinge Pin
- 3.35 m (11 ft)
- Dump Height with Foundry Bucket
- 2.71 m (8 ft 11 in)
- Hydraulic Flow (Standard)
- 94.6 lpm (25 gpm)
- Hydraulic Flow (High Flow)
- 1,666.6 lpm (44 gpm)
- Hydraulic Pressure
- 4,000 psi (27,579 kPa)
- Hydraulic Horsepower (Standard)
- 37.5 kW (50.3 hp)
- Hydraulic Horsepower (High Flow)
- 66.0 kW (88.6 hp)
- Hydraulic Horsepower (High Flow/High Pressure)
- 76.6 kW (102.7 hp)
- Tire Size
- 14 x 17.5 14
- Tires
- PR Titan HD2000-II
- Length without Bucket
- 3.18 m (10 ft 5 in)
- Length with Foundry Bucket
- 3.83m (12 ft 7 in)
- Width without Bucket
- 1.99 m (6 ft. 7 in)
- Height to ROPS
- 2.21 m (7 ft. 3 in)
- Ground Clearance
- 0.25 m (9.7 in)
