The Marcrest 210 Baler is a high-capacity square baler designed to integrate with the Bale Baron 5250, forming a seamless windrow-to-bundle system. This baler is engineered to handle high volumes efficiently, producing 14″ x 18″ bales up to 1,000 bales per hours depending on bale weight. Driven by a 475-pound flywheel, the key features include a variable-speed camless pickup, a triple Rasspe tailless knotter, and an auto-reset driveline clutch for protection against power overloads. The Marcrest 210 requires a minimum of 125 horsepower for operation (165 horsepower with Bale Baron 5250) and weighs approximately 11,000 lbs.​
Here are the key specifications of the Marcrest 210 Square Baler:
Specifications
- Bale Size
- 14" x 18"
- PTO speed
- 540 rpm
- Flywheel
- 475 lb. (215 kg)
- Camless Pickup
- Standard
- Pickup Width
- 78" (198 cm)
- Pickup Drive
- 5
- Pickup Windgaurd
- Spring Adjustable Swath Roller with Tines
- Pickup Gauge Wheels
- 16/6.5-8 Foam Filled Swiveling
- Auger Protection
- Racheting Torque Limiter
- Auger Drive
- #60 Chain
- Rotor Protection
- Auto-Reset Torque Limiter
- Rotor Drive
- Gearbox
- Stuffer
- 3 Tine Crank Type
- Stuffer Drive
- Gearbox
- Stuffer Protection
- Shearbolt
- Plunger Speed (540)
- 120 Strokes/Min.
- Plunger Protection
- Auto-Reset Torque Limiter
- Knotters
- 3 Tailless
- Knotter Protection
- Shearbolt
- Knotter Fan
- Auto-Reversing Hydraulic
- Twine Storage
- 21 Balls
- Chamber Tension
- 3-Way Onboard Hydraulic
- Tires
- 19/45-17
- Suspension
- Standard Rubber Block
- Onboard Hydraulic System
- Standard ( Pickup Drive, Bale Tension, Knotter Fan)
- Baler Weight (approx)
- 11,000 lb. (4,989 kg)
- Hitch Weight (approx)
- 1,700 lb. (771 kg)
- Minimum HP Requirement
- 125 hp (165 hp for baler and 5250 Bale Baron)
- Tractor Hydraulics
- 1 single acting (for pickup lift)
Videos
Photos
The Marcrest 210 Square Baler will be part of the Equipment Demonstrations at Canada’s Outdoor Farm Show 2024. Check out all the equipment available!
