2024 Kioti CK3520 Tractor

2024 Kioti CK3520 HST

Engine

- Model 3H- TM4B
- Engine Manufacturer KIOTI
- Power 34.90 hp (26 kW)
- Displacement 111.40 cu. in. (1,826 cc)
- RPM 2,600 rpm
- Fuel Type Diesel
- Fuel Capacity 9 gal (34 L)

Transmission

- Transmission Hydrostatic
- Shuttle Hydrostatic
- Travel Speeds Forward 3 Ranges, w/ infinite speeds
- Travel Speeds Reverse 3 Ranges, w/ infinite speeds
- Travel Speeds Minimum Speed 0 mph (0 km/h)
- Travel Speeds Maximum Speed 14.88 mph (23.94 km/h)
- Travel Speeds Min Reverse Speed 0 mph (0 km/h)
- Travel Speeds Max Reverse Speed 10.41 mph (16.76 km/h)

PTO

- PTO Type Independent
- PTO Power 30.90 hp (23 kW)
- Rear Speed 540
- Mid Speed 2,000 (Optional)

Drive Train

- Brakes Wet Disc Type
- Clutch None
- Steering Hydrostatic Power Steering

Hydraulics

- Pump Gear
- Pump Capacity 11.30 gpm (42.90 lpm)
- Lift Capacity 1,631 lb (740 kg)

Hitch

- Type Three Point
- Category Category 1
- Control Type Position
- Lift Capacity 1,500 lb (680 kg)

Dimensions

- Width 54.50 in (1,385 mm)
- Height 92.90 in (2,360 mm)
- Wheelbase 65.70 in (1,670 mm)
- Ground Clearance 13.40 in (340 mm)
- Front Tread 48.20 in (1,225 mm)
- Rear Tread 47.60 in (1,210 mm)
- Turning Radius 8.96 ft (2.73 m)
- Weight 2,921 lb (1,325 kg)
- Length with Hitch 120.90 in (3,070 mm)
