Diamond C FMAX210-32 Trailer - Flat Deck

*Coming soon - Available early spring*

Diamond C FMAX 32' gooseneck trailer

Brand: Diamond C
Model: FMAX210-32
Color: Black
Dimensions: 8.5' x 27' (+ 5' BT)
Load type: Max Ramps

Length/Width - 32' x 102"
GVWR - 25,000 lb
Axles - 2 - 10,000 lb General Duty, Oil Bath
Dovetail - 60" Dovetail with 2" x 2" x 1/8" Angle Cleats (Max Ramps)
Brakes - Electric Drum
Suspension - Slipper-type leaf springs (5 leaves), spacing 48"
Hitch type - Gooseneck designed 12"
Frame - 16" Engineered Beam 2.0
Jack - 2 - 12,000 lb fold-down leg jacks
Floor - 2" Treated Lumber
Crossmembers - 3" I-Beam on 16" Centers w/ Formed Gussets
Coupler - 2-5/16" Ball - 25,000 lb Bulldog BX1
Storage - Diamond Plate Neck Box w/ Gas Shock Assisted Lid
Winch - Winch Tray
Lace Rail - 6" Channel Lace Rail
Stake pockets - 2" x 3/8" Rub Rail w/ Stake Pockets & Pipe Spools
Steps - Front retractable & middle pivoting
Lighting - All LED Lights
Sway control - Standard
Wiring - Sealed Wiring Harness
Tire size - 235/80R16 10 Ply Radial, Dually w/Spare
Wheel color - Black
Spare mount - Under-Frame Spare Mount

Delivery options available, ask your dealer for details.
