New Diamond C FMAX210-30 Trailer - Flat Deck

*Coming Soon- Available Early Spring*

Diamond C FMAX 30' Gooseneck Trailer

Make: Diamond C
Model: FMAX210-30
Colour: Various Colours
Size: 8.5' x 25' (+ 5' BT)
Loading Style: Max Ramps

Length/Width - 30' x 102" MR
GVWR - 25,000 lb
Axles - 2 - 10,000 lb General Duty, Oil Bath
Dove - 60" Dovetail with 2" x 2" x 1/8" Angle Cleats (Max Ramps)
Brakes - Electric Drum
Suspension - 5-Leaf Slipper Springs, 48" Spread
Pull Type - 12" Engineered Gooseneck
Frame - 16" Engineered Beam 2.0
Jack - 2 - 12,000 lb Drop-Leg Jacks
Floor - 2" Treated Lumber
Cross-Members - 3" I-Beam on 16" Centers w/ Formed Gussets
Coupler - 2-5/16" Ball - 25,000 lb Bulldog BX1
Storage - Diamond Plate Neck Box w/ Gas Shock Assisted Lid
Storage - 14" x 14" x 42" Underslung Box
Winch - Winch Tray
Lace Rail - 6" Channel Lace Rail
Stake Pockets - 2" x 3/8" Rub Rail w/ Stake Pockets & Pipe Spools
Steps - Front Retractable & Mid-Turn
Steps - Extra Retractable Steps (pair)
Lights - All LED Lights
Sway Control - Standard on 30 - 40' models
Wiring - Sealed Wiring Harness
Tire Size - 235/80R16 10 Ply Radial, Dually w/Spare
Wheel Color - Black
Spare Mount - Under-Frame
